EPSILON-250
EPSILON-250 – High torque and Hollow shaft
The EPSILON-250 is designed for a wide range of industrial robotics applications, offering high torque (250Nm nominal torque) and the ability to handle overload and collisions. Featuring a hollow shaft and motor integration plate, it allows for easy integration into your system. Its continuous output rotation enables robots to perform with unrestricted movement, while maintaining high precision and reliability in demanding industrial environments.
Product Specification | EPSILON-250:
- 250Nm Nominal Torque
- Continuous Output rotation
- Easy Integration
- Protection to chocks and collision
- Transparent Mechanism
| Specification | Unit | EPSILON-250 | EPSILON-CUSTOM | COMPONENT SET |
|---|---|---|---|---|
| Repeated torque | Nm | 250 | 1 - 500 | 1 - 500 |
| Maximum Input Operation Speed | rpm | >8,000 | >8,000 | >8,000 |
| Max. Lost Motion | arcmin | 0.8 | 0.8 | 0.3 |
| Diameter | mm | 120 | tailored | tailored |
| Length | mm | 160 | tailored | tailored |
| Output Rotation | degree | continuous | continuous | continuous |
| Weight | kg | 8 | tailored | tailored |
| Efficiency | % | >90 | >90 | >90 |
Other models of EPSILON-SERIES:
Applications for Archimedes Drive:
- Industrial Robots
- Welding Robots
- Ground Robotic
- Construction Robots
- Rescue Robots
- Underwater Exploration
- CNC Robotics
- Warehouse Robots
- Mobile Robots
- Delivery Robots
