DELTA-250
The DELTA-250 – High Torque and Accuracy
The DELTA-250 drive offers an exceptional torque-to-weight ratio, designed specifically for industrial robots that demand higher precision, increased payload capacity, and faster speeds. Ready to order with 250Nm nominal torque, the DELTA-250 also incorporates the advanced features of the Archimedes Drive, including True Zero backlash, low operating noise, and built-in overload protection for enhanced reliability.
Product specification | DELTA-250:
- High Accuracy and Precision
- High Torque
- Smooth Movement
- Extended cycle Lifetime
| Specification | Unit | DELTA-15 | DELTA-250 | DELTA-CUSTOM |
|---|---|---|---|---|
| Repeated Torque | Nm | 15 | 250 | Custom |
| Maximum Input Operation Speed | rpm | >8,000 | >8,000 | >8,000 |
| Max. Lost motion | arcmin | 0.3 | 0.3 | 0.3 |
| Diameter | mm | 72 | 120 | Custom |
| Length | mm | 60 | 180 | Custom |
| Efficiency | % | >90 | >90 | >90 |
| Output Rotation | degree | 270 | 270 | 270 |
| Weight | kg | 1 | 10 | Custom |
